CITE-N clients cannot simply be satisfied with the job we do… they must be impressed. To accomplish this, we strive to exceed our client's expectations. Our goal at CITE-N is to become our client's first choice for lab equipments Services. CITE-N is able to provide our clients with a variety of services. We are providing products with Prompt Technical support and ensured after-Sale Service support for Our customers. Our range of products cover Research & Lab equipment for all departments, Test Measuring instruments, Variable power supplies, Analytical/Clinical Instruments, Audio/Video products etc. CITE-N is an Electronic Manufacturing Company in Kerala, India. Our experienced staff of professionals has worked with a wide array of platforms, designs, and tools in the course of our various projects. We have extensive experience in many diverse areas of both equipments manufacturing and sales development. Based in a educational institution network.
#Digital ic trainer kit full
Supplied with easy guidelines and full function instruction manual.CITE-N Education Network is a niche provider of Educational Lab Equipments sales and Services. #Digital ic trainer kit Patch
Trainer supplied with 7 pairs of red and black 2mm patch cords. Connections made up with 2mm brass pins. Bread board with size 170mmX62mm, 850 test points. Potentiometer 100K For general applications. The pulse width of clock can be varied with the help of potentiometer from 10 Hz to 1000 Hz. Low frequency selectable clock of 100Hz & 1000Hz selectable by switch. To operate the sequential circuit in digital electronic lab. Continuity tester for circuit connectivity. #Digital ic trainer kit zip
Power supply for bread board and zip socket also available separately.
Trainer equipped with 3 pin fused power inlet with 3 pin computer compatible power cord. Trainer contains 4 bit BCD to 7 segment indicator with inputs A, B, C, D inputs. Trainer contains 8 bit logic switches for logic 0/1 inputs and 8 bit logic output indicator by LED. #Digital ic trainer kit code
The following ICs are provided on the trainer set IC De-multiplexer/decoder 74138 (1), multiplexer 74153, encoder bcd to grey code & vice versa converter, shift register74194, binary counter 7493, magnitude comparator 7485, dual JK flip flop 7476(2), Dual D flip flop 7474 (2). 20 pin zip socket to test the SIP/DIP IC’S such as Multiplexer, De-multiplexer, Encoder, Decoder, Shift Register, Parity checker, Counters. of patch cords stackable from rear both ends 4mm spring loaded plug length ½ meter.
* The unit is operative on 230V ☑0% at 50Hz A.C.
Mains ON/OFF switch, Fuse and Jewel light. LEDs for visual indication of output status of each flip-flop. Two, 7-segment displays to monitor the output in decimal code. Three Band switches for various interconnections required in the circuit to provide greater convenience and avoiding wrong connections. Two Pulser switches for clear and clock arrangement.
Completely programmable panel to make any type of counter or shift register. A square wave oscillator of frequency 10 Hz, 1 KHz and 10 KHz with coarse and fine variations, demonstrate the basic principle of frequency division. A 4-bit binary counter to demonstrate the basic principles of frequency measurement. Five, J-K master slave flip-flops with preset and clear arrangement. at 1Amp, IC Regulated Power Supply Internally connected. įeatures: The board consists of the following built-in parts: The experiments performed by this kit (And, Or, Not, Nand, Nor, Xor, X-Nor, Counter, Flip-Flop, Register, Multiplexer, De-multiplexer operation).
